Tips for Installing Electrical Boxes

Installing electrical boxes is one of the first stages in electrical rough-in work. It is regarded as very easy work—more like carpentry than electrical wiring—but there still some common errors that DIYers frequently make. Follow these easy tips to make sure your electrical box installations look professional and meet code requirements.

Install Wall Boxes at Uniform Heights

It surprises some novice DIYers to learn that there are no precise code guidelines for how high wall switches or outlet boxes should be positioned. But professionals follow certain standards for a uniform look.

It’s standard practice for wall switches to be installed about 48 inches above the floor, but this distance can range from 43 to 53 inches, depending on your preference. For spaces used by people with accessibility issues requiring a wheelchair, for example, lower switch heights might be practical.

Common practice for receptacle outlet boxes is to install them so the bottom edge is between 12 and 16 inches above the floor. This distance, too, can be adjusted for special circumstances.

For switches and outlets above countertops, install them so the bottoms are about 4 inches above the countertop surface.
